The Diamondback is loaded with features! First, the solid one-piece aircraft-grade aluminum alloy construction makes the Diamondback rifle scope virtually indestructible and highly resistant to magnum recoil. Argon purging puts waterproof and fog proof performance on the agenda, and advanced fully multi-coated optics raise an eyebrow when crystal clear, tack-sharp images appear in the crosshairs. Look for all this and more in a rifle scope you'd expect to cost quite a bit more-but doesn't. We can live with that.

Optical Features

• Fully Multi-Coated : Increases light transmission with multiple anti-reflective coatings on all air-to-glass surfaces
• Second Focal Plane Reticle : Scale of reticle maintains the same ideally-sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.

Construction Features

• Tube Size : 1-inch diameter.
• Single-Piece Tube : Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
• Aircraft-Grade Aluminum : Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
• Waterproof : O-ring seals prevent moisture, dust and debris from penetrating the rifle scope for reliable performance in all environments.
• Fog proof : Argon gas purging prevents internal fogging over a wide range of temperatures.
• Shockproof : Rugged construction withstands recoil and impact.
• Hard Anodized Finish :Highly durable low-glare matte finish helps camouflage the shooter's position.
• Precision-Glide Erector System : Uses premium components in the zoom lens mechanism to ensure smooth magnification changes under the harshest conditions.
• Capped Reset Turrets : Allow re-indexing of the turret to zero after sighting in the rifle scope. Caps provide external protection for turret.

Convenience Features

• Fast Focus Eyepiece : Allows quick and easy reticle focusing.
• 2-7x35 Diamondback Rimfire has a 50-yard parallax setting which makes it ideal for use at close range on 22 rimfire, shotguns and muzzleloaders.
• V-Plex reticle is the single best all-purpose hunting reticle intended for a wide variety of hunting applications.
• Parallax is set at 50 yards.

Specifications

• Magnification : 2-7 x
• Objective Lens Diameter : 35 mm
• Eye Relief : 3.1 inches
• Field of View : 64.3-19.3 feet/100 yards
• Tube Size : 1 inch
• Turret Style : Capped
• Adjustment Graduation : 1/4 MOA
• Travel per Rotation : 15 MOA
• Max Elevation Adjustment : 100 MOA
• Max Windage Adjustment : 100 MOA
• Parallax Setting : 50 yards
• Length : 11.6 inches
• Weight : 14.2 ounces
